NanoCOM-TGU is powered by the 11^th Generation Intel® Core™ SoC is designed for applications with intensive data and graphic processing needs. The SoC integrates both powerful CPU and GPU, as well as AI and Deep Learning acceleration engines, to accelerate processing capability in embedded mobile applications, such as telematics, public sectors, and Industrial automation.

The mini form factor of COM Express Type 10 of NanoCOM-TGU shortens the design and deployment processes for system designers or integrators in their embedded mobile projects. In addition, by leveraging the Type 10 form factor, NanoCOM-TGU offers the high-speed I/O interfaces to shorten the system design, including one 2.5 Gigabit Ethernet, two display outputs (eDP x 1 and DDI x 1), one high-definition audio output, two SATA 3.0 interfaces, one onboard PCIe NVMe SSD (up to 256GB), ten USBs (USB 2.0 x 8 and USB 3.2 Gen 2 x 2), two UARTs and PCI-Express [x1] x 4.

To meet the required memory bandwidth and storage performance, NanoCOM-TGU supports LPDDR4x memory with in-band ECC up to 16GB for IoT and Big Data related applications. The onboard PCIe NVMe SSD interface supports up to 256GB and accelerates read/write speeds multiple times than conventional storage interfaces.

System designers or integrators can also be benefited from graphical processing power enabled by Intel® UHD Graphics in NanoCOM-TGU for enhanced visual performance.
